Description
HUBEE MINI: USB-C DOCKING STATION MULTI DISPLAY 4K WITH POWER DELIVERY 100W
The HUBEE MINI docking station design is slim and compact to offer natural heat dissipation, it integrates a very resistant cable that offers great durability. This multi-stream docking station supports triple display for computers compatible with USB-C video alternate mode. It supports resolutions up to 1080p and if only one DP or HDMI screen is connected, the display will reach 4K 30Hz resolution. The USB-A ports of the docking allow you to extend the use of USB peripherals such as an external hard drive, keyboard, mouse or headset. HUBEE mini will become your computer's essential companion.
Key Features
- The HUBEE MINI docking station design is slim and compact to offer natural heat dissipation, it integrates a very resistant cable that offers great durability. This station supports triple display for computers compatible with USB-C video alternate mode. (Resolution up to 4K 30Hz). The USB-A ports of the Docking allow you to extend the use of USB-A peripherals. The integrated Gigabit Ethernet port will allow you to download ultra fast
- 1. USB-C: Power supply 100W / 550mm Cable
- 2. Single Display Port: 4K/30Hz max
- 3. Single HDMI Port: 4K/30Hz max
- 4. Single VGA Port: 2K/60Hz max
- 5. USB-A 3.0 Ports: 5Gbps
- 6. USB-A 2.0 Ports: 480Mbps
- 7. RJ45: Gigabit Ethernet 1000Mbps max
- 8. Card readers: SD / TF (MSD) up to 2TB
- 9. Jack socket: 3.5mm Stereo 4poles TRRS
- Supports:
- PXE BOOT (The station must be powered to use this function)
- Mac address PASSTHROUGH
Description
HUBEE MINI: 100W 4K MULTI-SCREEN USB-C STATIONThe HUBEE MINI docking station design is slim and compact to offer natural heat dissipation, it integrates a very resistant cable that offers great durability. This multi-stream docking station supports triple display for computers compatible with USB-C video alternate mode. It supports resolutions up to 1080p and if only one DP or HDMI screen is connected, the display will reach 4K 30Hz resolution. The USB-A ports of the docking allow you to extend the use of USB peripherals such as an external hard drive, keyboard, mouse or headset. HUBEE mini will become your computer's essential companion.
Specifications
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| VGA (D-Sub) ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Connectivity technology | Wired |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 100 W |
| DisplayPort version | 1.2 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Maximum digital resolution | 3840 x 2160 pixels |
| Number of displays supported | 3 |
| Country of origin | China |
| Product colour | Black |
| Card reader integrated | Yes |
| Compatibility | USB-C & Thunderbolt 3 Notebooks |
| Plug and Play | Yes |
| Maximum memory card size | 2 TB |
| LED indicators | Yes |
| Data transfer rate | 5 Gbit/s |
| Compatible memory cards | MicroSD (TransFlash), SD |
| HD type | 4K Ultra HD |
| Maximum refresh rate | 30 Hz |
| Technical details | |
| Product colour | Black |
| Compatibility | USB-C & Thunderbolt 3 Notebooks |
| Plug and Play | Yes |
| Data transfer rate | 5 Gbit/s |
| Storage | |
| Card reader integrated | Yes |
| Maximum memory card size | 2 TB |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Power | |
| Power cable length | 0.55 m |
| Software | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Indication | |
| LED indicators | Yes |
| Weight & dimensions | |
| Weight | 255 g |
| Width | 206 mm |
| Depth | 58 mm |
| Height | 19 mm |
| Design | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Mac operating systems supported | Yes |
| Country of origin | China |
| Product colour | Black |
| LED indicators | Yes |
