500 W, ATX, ATX 12V, 200 - 240 V, 1.17 kg, 150 x 140 x 85 mm
Description
Introducing the Vida Lite 500W PSU (AA-500-YY) – where power meets play without the shocking price tag! This ATX dynamo delivers a dazzling 500 watts of electrifying performance, keeping your system fully charged and ready for action. With a fully wired design for a direct power connection and an ultra-quiet 120mm black fan, this powerhouse ensures a cool and quiet operation. Featuring connectors that spark convenience, including 20+4 pin and SATA, it's compatible with ATX 12V systems and guarantees a shockingly smooth performance. Don't miss out on the Lite side of power – it's your ticket to a jolt of energy without the shocking aftermath. Backed by a 1-year warranty, the Vida Lite 500W PSU is where power meets practicality in a positively electrifying package.
Specifications
| Cooling |
|---|
| Fan diameter |
12 cm |
| Fan location |
Front |
| Performance |
|---|
| On/off switch |
Yes |
| Power supply unit (PSU) form factor |
ATX |
| 80 PLUS certification |
No |
| Purpose |
PC |
| ATX version |
1.3 |
| Country of origin |
China |
| Bearing technology |
Hydraulic |
| Design |
|---|
| 80 PLUS certification |
No |
| Product colour |
Black |
| Fan diameter |
12 cm |
| On/off switch |
Yes |
| Fan location |
Front |
| Country of origin |
China |
| Power |
|---|
| Total power |
500 W |
| Peak power |
500 W |
| AC input voltage |
200 - 240 V |
| AC input frequency |
50/60 Hz |
| Power Factor Correction (PFC) type |
Passive |
| Max output current (+3.3V) |
30 A |
| Max output current (+12V) |
18 A |
| Max output current (+5V) |
36 A |
| Max output current (-12V) |
0.5 A |
| Max output current (+5Vsb) |
2.5 A |
| Power protection features |
Over power |
| Number of +12V rail(s) |
1 |
| Ports & interfaces |
|---|
| SATA power cable length |
800 mm |
| Peripheral (Molex) power cable length |
800,1000 mm |
| CPU power cable length |
58 cm |
| Motherboard power connector |
24-pin ATX |
| Number of SATA power connectors |
6 |
| Peripheral (Molex) power connectors (4-pin) |
1 |
| CPU power connector (4+4 pin) |
Yes |
| PCI Express connector |
No |
| Floppy disk drive connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| Cabling type |
Non-Modular |
| EPS power connector (4+4 pin) |
Yes |
| Number of EPS connectors |
1 |
| Number of SATA power cables |
2 |
| Certificates |
|---|
| Compliance certificates |
UKCA, CE, RoHS |
| 80 PLUS certification |
No |
| Weight & dimensions |
|---|
| Width |
150 mm |
| Depth |
85 mm |
| Height |
140 mm |
| Weight |
1.17 kg |
| Packaging data |
|---|
| Package depth |
92 mm |
| Package width |
195 mm |
| Package height |
160 mm |
| Package type |
Box |
| Package weight |
1.4 kg |
| Technical details |
|---|
| Compliance certificates |
UKCA, CE, RoHS |
| Logistics data |
|---|
| Country of origin |
China |
