Description
Active powered Subwoofer 8" 50W + 2x25W 2.1
Ideal for meeting rooms, hotels and auditoriums.
It have line input and loop out for active sattelite speakers.
Subwoofer can also be used together with passive sattelite speakers using the internal power amplifier for sattelige speakers on 2 x 25W
• For rooms up to 200m2
• Power effect for subwoofer: 50 Watts
• Power effect for passive ceiling speakers:
(VLSPMTC60WT) 2x25Watts
• Inputs: 100V, Balanced in and RCA line in
• Bluetooth input for speaker out only (not supported for line-out)
• Outputs: RCA line out and Speaker out 2x 25W
• Line out for active speakers (VLSP60/65/61/70)
• Frequency range: 80Hz-20kHz
• Impedance: 8 Ohm
Key Features
- Active powered Subwoofer 8" 50W
- 2x25W speaker output + line- out
- Silent on/off via automatic ECO mode after 90 seconds (less than 0,5 Watt)
- Audio inputs: 2xRCA + 100V + Balanced input + Bluetooth for (speaker out only)
- Switchable stereo / mono output
Description
Vivolink Active Subwoofer is a perfect match to all Vivolink speakers. It is designed to be mounted over ceiling or under funitureIdeal for meeting rooms, hotels and auditoriums.
It have line input and loop out for active sattelite speakers.
Subwoofer can also be used together with passive sattelite speakers using the internal power amplifier for sattelige speakers on 2 x 25W
• For rooms up to 200m2
• Power effect for subwoofer: 50 Watts
• Power effect for passive ceiling speakers:
(VLSPMTC60WT) 2x25Watts
• Inputs: 100V, Balanced in and RCA line in
• Bluetooth input for speaker out only (not supported for line-out)
• Outputs: RCA line out and Speaker out 2x 25W
• Line out for active speakers (VLSP60/65/61/70)
• Frequency range: 80Hz-20kHz
• Impedance: 8 Ohm
Specifications
| Loudspeakers | |
|---|---|
| Speaker placement | Ceiling-mountable |
| Number of drivers | 3 |
| Amplifier | Built-in |
| Woofer | Yes |
| Woofer diameter (imperial) | 20.3 cm (8") |
| Subwoofer RMS power | 50 W |
| Audio output channels | 2.1 channels |
| Audio | |
| Speakers RMS power | 60 W |
| Frequency range | 40 - 20000 Hz |
| Impedance | 4 Ω |
| Crossover frequency | 200 Hz |
| Subwoofer RMS power | 50 W |
| RMS rated power | 110 W |
| Performance | |
| On/off switch | Yes |
| Product colour | Black |
| Magnetically shielded | Yes |
| Housing material | Plastic |
| Volume control | Rotary |
| Certification | CE |
| Technical details | |
| Product colour | Black |
| Magnetically shielded | Yes |
| Volume control | Rotary |
| Certification | CE |
| Front speaker impedance | 4 Ω |
| Front speaker frequency range | 80 - 20000 Hz |
| Housing colour | Black |
| Case colour | Black |
| Accessories included | AC Power Cord |
| Warranty period | 3 year(s) |
| Design | |
| Product colour | Black |
| Housing material | Plastic |
| Certification | CE |
| Amplifier | |
| Amplifier class | D |
| Number of amplifier channels | 3 channels |
| Amplifier | Built-in |
| Amplifier output power | 110 W |
| Amplifier output power (woofer) | 50 W |
| Amplifier output power (tweeter) | 30 W |
| Ports & interfaces | |
| Connectivity technology | Wired |
| 3.5 mm (1/8-inch) in | Yes |
| 6.35 mm (1⁄4-inch) input | 1 |
| Audio RCA inputs | 1 |
| Management features | |
| On/off switch | Yes |
| Power | |
| Power consumption (typical) | 75 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 230 - 240 V |
| Power source type | AC |
| Current | 1 A |
| Material | |
| Housing material | Plastic |
| Weight & dimensions | |
| Width | 178 mm |
| Depth | 162 mm |
| Height | 240 mm |
| Weight | 6.26 kg |
| Speaker weight | 6.36 g |
| Package width | 440 mm |
| Package depth | 210 mm |
| Package height | 265 mm |
| Package weight | 6.75 kg |
| Packaging data | |
| Package width | 440 mm |
| Package depth | 210 mm |
| Package height | 265 mm |
| Package weight | 6.75 kg |
| Packaging content | |
| Mounting brackets included | Yes |
| Manual | Yes |
| Cables included | AC |
| Features | |
| Front speaker impedance | 4 Ω |
| Front speaker frequency range | 80 - 20000 Hz |
| Housing colour | Black |
| Case colour | Black |
| Accessories included | AC Power Cord |
| Other features | |
| Front speaker impedance | 4 Ω |
| Front speaker frequency range | 80 - 20000 Hz |
| Housing colour | Black |
| Case colour | Black |
| Accessories included | AC Power Cord |
| Number of amplifier channels | 3 channels |
| Speaker weight | 6.36 g |
| Manual | Yes |
| Magnetically shielded | Yes |
| Subwoofer RMS power | 50 W |
| Audio (L/R) in | 1 |
| Adaptor plug | EU |
| Audio output channels | 2.1 channels |
